Brand Name : SPR-ing
Model Number : SP045028-G18
Place of Origin : Shenzhen
MOQ : 1 piece
Price : 200~800 USD
Payment Terms : L/C,T/T
Supply Ability : 1000/month
Delivery Time : 1~3 weeks
Packaging Details : Carton
Working loops : 12-20-28 channels are optional
Insulation resistance : ≥110MΩ/250V/DC
Contact Material : Gold-gold
Rated voltage/current : 80VDC/1A
Electrical strength : ≥250VAC/50Hz/60s
Rated speed : 2000-18000 rpm
Working life : 100 million revolutions
High-speed slip rings are one of the core key technologies of our company. This high-speed slip ring adopts the latest technology and technology, no cooling device is the biggest feature of the product, both ends of the wire output, the maximum application speed of 18000 rpm, according to the actual needs of different speeds.
Electrical Specifications | |
Working loops | 12-20-28 channels are optional |
Insulation resistance | ≥110MΩ/250V/DC |
Rated voltage/current | 80VDC/1A |
Electrical strength | ≥250VAC/50Hz/60s |
Dynamic resistance change value | ≤10mΩ |
Wire length | Standard 600mm (can be adjusted on request) |
Mechanical technical indicators | |
Rated speed | 2000-18000 rpm |
Working life | 100 million revolutions |
Operating temperature | -20℃~80℃ |
Operating humidity | 25~95%RH |
Contact with the material | Kim-Kim |
Housing material | 304 stainless steel |
Maximum starting torque | <2N.cm |
Ingress protection | IP65 |
Our Mini Slip Ring product technical support team is dedicated to providing assistance with any product-related queries or issues. Whether you have questions about installation, operation, or troubleshooting, our experts are here to help.
In addition to technical support, we offer a range of services to ensure optimal performance of your Mini Slip Ring. This includes maintenance, repair, and customization services tailored to meet your specific needs.
Product Packaging for Mini Slip Ring:
The Mini Slip Ring will be securely packaged in a compact box to ensure safe transportation and delivery.
Product Shipping for Mini Slip Ring:
Orders of the Mini Slip Ring will be carefully packed and shipped within 1-2 business days of purchase. Customers can choose their preferred shipping method during checkout.
Q: What is the brand of the Mini Slip Ring product?
A: The brand name is SPR-ing.
Q: What is the model number of the Mini Slip Ring product?
A: The model number is SP025.
Q: Where is the Mini Slip Ring product manufactured?
A: The product is made in Jiujiang.
Q: What is the minimum order quantity for the Mini Slip Ring product?
A: The minimum order quantity is 1.
Q: What are the available payment terms for purchasing the Mini Slip Ring product?
A: The payment terms accepted are L/C and T/T.
![]() |
